HTI MicroCC-20 VET

Contact Us

Manufacturer: HTI (USA)
3-part differential automated veterinary hematology analyzer

System Function
Throughput: 60 samples per hour
Parameters: (20) WBC, LYM#, MON#, GRA#, LYM%, MON%, GRA%, RBC, HGB, MCHC, MCH, MCV, RDW‐CV, RDW‐SD, HCT, PLT, MPV, PDW, PCT, P-LCR and histograms for WBC, RBC and PLT
Multiple Animal Species: 9 Predefined Programs (Cat, Dog, Rabbit, Pig, Horse, Goat, Monkey, Cow, Buffalo) 4 User Defined
Sample Volume: Prediluted 20μL Whole Blood 9.8μL
Sample Processing: Open Tube or Cup, Manual Feed, Retractable Sample Probe
Reagents: Lyse, Diluent, Cleanser, Cleaner Concentrate (maintenance)

Measuring Principles
  • WBC Measurement:Method: Impedance
  • Aperture (Ruby): 80um
  • Count Time: 2 (or 3) x 5 sec
  • Dilution Ratio: 1:269
  • 3 Part Differentiation:Method: Impedance + specific Lyse
  • Hgb Measurement:Method: Photometry
  • Wavelength: 550nm
  • Count Time: 2 (or 3) x 5 sec
  • RBC/MCV/PLT Measurement:Method: Impedance
  • Aperture (Ruby): 80um
  • Count Time: 2 (or 3) x 5 sec
  • Dilution Ratio: 1:17906
  • HCT, MCH, MCHC, RDW:Calculated
Software:
Display: 10.4" LCD, Color touchscreen
Operating System: Windows
Language: English, Spanish, Russian, French, Ukrainian
Memory: 250,000
Design: User Friendly, Rapid Access to Menus, Virtual Keyboard, User Profile (Access Level restrictions), Result Data Review
Calibration: Automated, Manual
Quality Control: 20 QC Files x 500 results; calculation of mean, SD, CV% per parameter, QC database, automatic charts, L-J of 500 results, X-B - 2000 QC data, X-R - 60 group (max 10 number of samples in each group)
Connectivity: RS-232, USB x2, RJ-45 (Ethernet), LPT, PS/2 x2, LIS (output only), external printer capable, external mouse, keyboard & barcode reader
Printer: Built-in thermal printer, 55mm paper
Alerts: Real-time messages, automatic maintenance and optional alerts, reagent level monitoring

Working Condition
Power Supply: 110 ~ 240V, 50/60Hz, 96VA
Temperature: 15°~ 35°C
Humidity: 10 ~ 90%
Dimension: 43.6cm x 36.7cm x 36.3cm (W x H x D)
Weight: 18kg
